Comprehensive and intuitive shaft alignment utilising tablets and smartphones

The TKSA 51 shaft alignment tool provides high measurement flexibility and performance suitable for entry-level to expert alignment jobs.

Designed to work with the shaft alignment for TKSA 51 app on a tablet or smart phone, this intuitive tool is easy to use and requires no special training.

The included accessories enable use of the TKSA 51 for a wide range of alignment applications, such as motors, drives, fans, pumps, gearboxes and more. The tool's mobile app includes tutorial videos to show operators how to perform accurate measurements.



App: TKSA 51

The TKSA 51 App is available for free in the Apple App Store or on Google Play Store. Just search for “SKF shaft alignment” with your device and try the alignment process with the fully functional demonstration mode.

App: Soft Foot for TKSA51

The SKF vertical shaft alignment and the SKF soft foot function are available via an additional app. Just search for "TKSA 51 Soft Foot" in the Apple Appstore and/or the Google Play Store or use the QR Scan Code on this page with your mobile device.

Shaft alignment tool TKSA 51
Shaft alignment tool TKSA 71
  • Features and Benefits

    • Measurement flexibility - The well-known, three-position measurement gains additional flexibility as measurements can start at any angle and require a total minimal rotation of only 40 degrees. This enables operators to perform alignments on applications with limited space.
    • Automatic reports - Alignment reports are generated automatically and can be customised with notes, a machine picture and a signature via touchscreen. These reports can be exported as PDF files and shared with other mobile apps.
    • Comprehensive and compact - A range of included components, such as magnetic mounting brackets and extension rods and chains, increase the TKSA 51's versatility, yet it remains compact, lightweight and easy to carry.
    • 3-D live view - This feature enables intuitive positioning of heads for quick alignment measurements and displays live when horizontal/vertical alignment correction is achieved. The app enables 3-D rotation of the virtual motor to correspond with the actual machine position.
    • Disturbance compensation - Measurement values are averaged over time to provide accuracy in presence of vibration or other external disturbances.
    • Fully functional demo mode - The app can be downloaded easily, and its demonstration mode allows the shaft alignment process to be experienced before purchasing the TKSA 51.
  • Technical Data

    Sensors and communication
    20 mm (0.8 in.) PSD with red line laser Class 2; electronic inclinometer ±0,1°; Bluetooth 4.0 LE
    System Measuring distance
    0.07 to 5 m (0.23 to 16.4 ft)
    Measuring errors / displayed resolution
    <1% + 1 digit
    Compatible operating devices *
    iPad Mini recommended, iPad 3rd generation or above, iPod Touch 5th generation or above iPhone 4S or above
    Operating system requirements
    Apple iOS 8 or above
    Software / App update
    via Apple App Store
    Shaft diameters
    20 to 150 mm (0.8 to 5.9 in.), up to 450 mm (17.7 in.) with extension chains supplied
    Max. recommended coupling height
    170 mm (6.7 in.) with extension rods
    Alignment measurement
    3 × positions free measurement (min. 40° total angle), automatic measurement
    Alignment correction
    Live values for vertical and horizontal machine position correction Adjustable shocks compatible (Vibracons)
    Soft foot correction
    Available with separate "Soft Foot for TKSA 51" app on Apple App Store
    Alignment report
    Automatic pdf report exportable via email/cloud services
    Display orientation
    Landscape (plus portrait on tablets)
    Measuring unit battery
    Up to 10 hours continuous operation (2 000 mAh rechargeable Li-ion battery)
    Carrying case dimensions
    355 × 250 × 110 mm (14 × 9.8 × 4.3 in.)
    Total weight (incl. case)
    2,9 kg (6.4 lbs)
    Operating temperature
    0 to 45 °C (32 to 113 °F)
    IP rating
    IP54
    Calibration certificate
    Supplied with 2 years validity
    Warranty
    2 years standard warranty + 1 additional year upon registration
